2004–2006 Jeep LJ suspension upgrade featuring a front 3-link and rear double-triangulated 4-link long-arm system—designed without front frame stretching for enhanced durability and articulation.

Description

2004-06 Jeep Wrangler LJ 3-Link Front/4-Link Rear Double Triangulated Long Arm Upgrade. We wanted to change the LJ suspension game. Our kit is a true double triangulated rear to minimize rear steer.

We offer stock length, 4 Inch and 7 inch rear stretch options. We made our skid plate so that it can be removed without holding up the transmission.

Kit includes:

• No truss no rear stretch no front stretch no link Upgrade
• Weld-in side brackets with integrated front link mounts
• Third link mount for Axle side
• Bolt-in rear crossmember for double triangulation
• Truss top 4-link mounts
• Axle side lower control arm mounts
• Bolt-in transmission mount cross member
• (1) Skid Plate 1/4 Inch laser cut and CNC smooth bottom
• (4) 2 Inch 7075 T6 Aluminum lower links w/Rock Jock narrow joints at both ends
• (1) 1.75 Inch 7075 T6 Aluminum upper link w/Rock Jock narrow joints at both ends
• (2) 2 Inch Solid 7075 T6 Aluminum upper links with narrow Rock Jock Johnny Joints
• Includes all grade 8/10.9 hardware

This kit requires:

• Welding brackets to frame and Axles
• Factory fuel tank must be relocated for stretch kits
• Rear Axle to have a truss (not included)
• Evaporative canister will need to be relocated with stretch kits
• Exhaust will need to be customized
